EBVText
EBVText settings
EBVText
When Argument is specified as
<dim>, you can put unit suffix after the value (e.g. 0.1nm).
If no unit suffix is specified, [um] is assumed.
Multigon/Show Curve Section as Polygon of Control Points
--ebvtext-multigon-as-control-polygon
[<on|off>]
(off)
Specifies whether to display curve section as a polygon of control points.
Multigon/Show Control Points
--ebvtext-multigon-with-control-point
[<on|off>]
(off)
Specifies whether to display control points of parametric curve.
Coordinates Correction/Correct Coordinates to Fit on Grid
--ebvtext-grid-on
[<on|off>]
(off)
Specifies whether to correct the vertex coordinates so that each vertex is placed on the grid with unit specified by --ebvtext-grid-unit spacing.
Coordinates Correction/Unit for Coordinates Correction Process
--ebvtext-grid-unit
[<dim>]
(0)
Specifies the unit to be used for coordinates correction process. If 0 is specified, the address unit of the EBV Text file is used.
